SCAME Pin & Sleeve Male Plug 30A/32A 250VAC 2P 3W IP67 Watertight

SCAME male pin and sleeve plug, dual-rated for 30A/32A single-phase applications. Rated for 250VAC with a 2-pole, 3-wire configuration and 6h ground-pin position. The IP67 watertight construction is suitable for wet and demanding environments.

Specifications

• Configuration: Male plug
• Amperage: 30A/32A
• Voltage: 250VAC
• Poles/Wires: 2 Pole, 3 Wire
• Clock position: 6h
• Protection rating: IP67 Watertight
• Cable size: #10 AWG to #8 AWG
• Cable outside diameter: 0.675 to 0.910 inches
• Color: Blue
• Material: Valox housing with neoprene seals
• Standards: IEC 60309-1 and IEC 60309-2
• Country of manufacture: Italy
• Compatible with: 330C6W and 330R6W
